High performance crusher wear parts

  • Specification:HB200,F4,F9,SB 300,SB 400
  • Application:Mine digging,civil foundation,broken stone
  • Length:510-720mm
  • Diameter:70-610Smm
[email protected]

Introduction:

Crusher wear parts is accessory of crusher.Different crusher need the drill rod with specialized size and the tail shape.Due to working strength requirement for drill rod,they need to use this tools with high wear resistance, high strength, high hardness.In order to meet different customers demands, our company developed the different materials of drill rod,our company's hot sale products are SB - 81, SB to 40, 45, SB - SB - 50, GB2T, GB8AT, GB8T.

Features:

High strength,hardenss,wear-resistance

The hammer breaker rod is processed with special heat treatment to ensure the breaker rod has enough hardness and toughness .

Extend its using life 10%-15% than normal drill rod

Application range of crusher wear parts is wide, including road construction and maintenance, housing demolition, the tunnel digging, and so on.It is suitable for crusher brands: KOKU,HANWOO,etc



Crusher name Drill rod type Diameter(mm) Length(mm)   Crusher name Drill rod type Diameter(mm) Length(mm)
KOKU TNB-1E 50 500   HANWOO RHB301 45 480
TNB-2E 58 590   RHB303 50 490
TNB-4E 75 710   RHB304 58 600
TNB-5E/6E 95 800   RHB305 68 750
TNB-7E/8E/10E 115 930   RHB306 80 850
TNB-13E 135 1150   RHB309 85 900
TNB-14E/16E 135 1150   RHB313 105 1050
TNB-150 135 1200   RHB320 125 1150
TNB-190 140 1200   RHB321 130 1200
TNB-22E 145 1200   RHB322/325 135 1200
          RHB328/330/332 150 1450
          RHB333 155 1450
          RHB340 165 1450
          RHB350 180 1600
